SpeakerCraft® 5.25" White In-Wall Speaker

SpeakerCraft

Model #:

PROFILE AIM CINEMA ONE

Model #: PROFILE AIM CINEMA ONE
796242
SpeakerCraft
$557.00

At a Glance

Product Dimensions 30.25"h x 9"w x 4"d

AIM Series in-ceiling speakers were the first to feature an aimable woofer/tweeter module that aims the sound in any direction you choose. No longer are you bound by the design of your room. Just mount the speakers wherever it’s convenient and point them wherever you want sound.Read More

Available in Store Only
$557.00

Get to know this product.

Product Overview

Product Overview

AIM Series in-ceiling speakers were the first to feature an aimable woofer/tweeter module that aims the sound in any direction you choose. No longer are you bound by the design of your room. Just mount the speakers wherever it’s convenient and point them wherever you want sound. Profile grilles are available in AIM8, AIM7 and AIM5 models.

Flangeless Appearance

Pivoting 1″ Silk Dome Tweeter

Two 5¼” Injection Molded Graphite Cone Woofers with Phase Plugs

Two 6″ Kevlar® Impregnated Paper Cone Woofers

Front-Mounted Bass Adjustment Switch

Bi-Amping Feature

Useful Documents
Brochure
Manual
Installation Guide
Specifications

General Specs

Cut Out Width7.5
Cut Out Height28.75
Frequency Response40Hz – 20kHz
Color Finish NameWhite
Shipping Width (in.)8.2
Shipping Height (in.)11.6
RMS Power Handling (Watts)125
ColorWhite
Impedance8 ohms
Sensitivity89
Speaker TypeIn-Wall Speakers
Depth (in.)4
Height (in.)30.25
Width (in.)9

General

FamilyProfile AIM Cinema
Woofer Size5.25 (Inches)
Woofer ConstructionTwo 5¼” Injection Molded Graphite Cone Woofers with Phase Plugs . Two 6″ Kevlar® Impregnated Paper Cone Woofers
Frequency Response40Hz – 20kHz
Impedance8 (Ohms)
Sensitivity89 (dB)
TimbreTimbre-Matched to All One Series Speakers
Dimensions(H x W x D) 30 1/4″ x 9″ x 4″ (768 mm x 229 mm x 102 mm) (with Grille)
Hole Cutout Dimensions(H x W) 28 3/4″ x 7 1/2″ (730 mm x 191 mm)

Shipping Info

Length33.3 (Inches)
Width8.2 (Inches)
Height11.6 (Inches)
Weight17.15 (Lbs)
